Rod oil pump

The rod oil pump can be fixed and sealed as a whole at
the predetermined position when the sucker rod is lowered
into the tubing, so it is also called "plug-in oil well pump".
The rod type oil well pump does not need to trip the tubing
during the operation of lifting and lowering the oil well
pump, which is convenient, time-saving and labor-saving,
and takes up a short time in the well; at the same time, it
reduces the screwing up and unloading operation of the oil
pipe, reduces the potential leakage of the oil pipe thread,
extends the service life of the oil pipe, and is good for the
maintenance of the oil pipe.

Product introduction:

The rod type oil well pumps produced by us include fixed barrel top-fixed rod type oil well pump (RHA or RWA), fixed barrel

bottom-fixed rod type oil well pump (RHB or RWB) and movable barrel bottom-fixed rod type oil well pump (RWT or RHT).

According to the support type, we can provide leather cup support and mechanical support. The product conforms to API

Spec 11AX Specification for SubsurfaceSucker Rod Pumps and Fittings.

Main technical parameters:

Model	Nominal Dia. (in) mm	Barrel Lengt h(ft) m	Plunger Length （ft） m	Stroke （ft）	Tubing and Thread （EUE/NUE）	Sucker Rod （in）
20-125RHAC/M	32(1.25)	2–10 (7–34)	0.3–7.9 (1–26)	1.2–8.8 （4-29）	2-3/8	3/4
25-150RHAC/M	38(1.50)				2-7/8	3/4
25-175RHAC/M	44(1.75)				2-7/8	3/4
30-225RHAC/M	57(2.25)				2-7/8	3/4
20-125RHBC/M	32(1.25)				2-3/8	3/4
25-150RHBC/M	38(1.50)				2-7/8	3/4
25-175RHBC/M	44(1.75)				2-7/8	3/4
30-225RHBC/M	57(2.25)				3-1/2	3/4
20-125RHTC/M	32(1.25)				2-3/8	3/4
25-150RHTC/M	38(1.50)				2-7/8	3/4
25-175RHTC/M	44(1.75)				2-7/8	3/4
30-225RHTC/M	57(2.25)				3-1/2	3/4
