Full-barrel pump

The full-barrel pump developed by us is designed and manufactured in accordance with GB/T18607, API Spec 11AX and other standards, with domestic advanced technology, having advantages of reasonable design, high pumping efficiency, corrosion resistance, wear resistance, long pump inspection cycle, and so on. The company produces not only standard tubular pumps, but also special pumps such as sand-proof pumps, anti-gas pumps, bridge pumps, inclined well pumps, tandem feedback pumps, and stratified production and mixing pump.

Technical performance characteristics:

① The pump barrel applies high-quality special pipes, and the inner surface applies surface strengthening treatment such as chromium

plating or nickel phosphorus composite plating, with high strength, good rigidity and wear resistance.

② The plunger surface is spray welded with nickel base alloy powder, which is wear-resistant.

③ The valve ball and valve seat are made of high carbon chromium stainless steel or tungsten carbide, titanium carbide and other materials,

with long service life.

④ High pump efficiency and long pump inspection cycle.

⑤ Simple structure, easy to use and install.

Specifications	Nominal diameter (mm)	Stroke (m)	Plunger length (m)	Outer diameter of connecting oil pipe (mm)	Pump constant (m³/d)	Diameter of connecting rod (mm)
25-125TH	31.75	0.6 ～ 9.0	1.2	73.0	1.140	19
25-150TH	38.10	0.6 ～ 9.0	1.2	73.0	1.642	19
25-175TH	44.45	0.6 ～ 9.0	1.2	73.0	2.235	19
25-225TH	57.15	0.6 ～ 9.0	1.2	73.0	3.691	19/22
30-250TH	63.50	0.6 ～ 9.0	1.2	88.9	4.560	19/22
30-275TH	69.85	0.6 ～ 9.0	1.2	88.9	5.518	22/25
35-325TH	82.6	0.6 ～ 9.0	1.2	101.6	7.707	22/25
35-375TH	95.3	0.6 ～ 9.0	1.2	114.3	10.261	25
